Siemens 6EP4135-0GB00-0AY0

Troubleshooting
4.1 Hardware fault
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
185
Error
Type
Ex-
tended
Error
Type
Severity
Alarm Text
Help Text
257 17 F UPS1600 parameters cor-
rupt
UPS1600-parameters corrupt - try to update the software.
257 18 F Device overtemperature Output and battery charging is switched off to prevent damage
to the device.
257 20 MR Low voltage mode Input voltage of UPS1600 is too low. UPS1600 is not ready for
buffering.
257
21
MR
Buffering
Device is in the buffer mode.
257 22 MR Communication with device
failed
PROFINET connection available - UPS1600 is defective
257
23
MR
Device powered up
Device powered up
257
24
F
Wrong battery polarity
Wrong battery polarity - check battery connections.
257 26 MR Insufficient charge level Set buffer time can currently not be achieved due to low bat-
tery charge.
257
27
MR
Deep discharge battery
Battery is deep discharged - no buffering possible
258 1 F Battery defective (battery
index: {1:d})
Battery defective - check the fuse and the battery voltages
258 2 F Deep discharge battery, no
charging possible (battery
index: {1:d}).
Battery is deep discharged - replace battery
258 3 MD Battery temperature high
(battery index: {1:d})
Battery temperature too high - battery life will be shortened
258 4 MD Battery temperature low
(battery index: {1:d}).
Battery temperature too low - reduced output current
258 5 F Communication with battery
fault (battery index: {1:d})
Communication with formerly known battery is no longer pos-
sible - check communication
258 6 MR New battery detected (bat-
tery index: {1:d})
A new battery was connected. The battery will be included in
the calculation of the total capacity and the charge parameters.
258 7 F Wrong battery configuration
(battery index: {1:d})
Different battery types connected. Only batteries of the same
type can be operated together.
258 8 MD Battery parameters corrupt
(battery index: {1:d}).
Battery defective - replace battery
Remark:
Alarm is deactivated.
258 9 MR Battery replacement started
(battery index: {1:d})
Battery replacement started by user
258 10 MR Battery replacement fin-
ished (battery index: {1:d})
Battery replacement finished - counters have been reset
258 11 MD Battery replacement can-
celed (battery index: {1:d})
Battery replacement canceled - battery parameters are not
reset
258 12 F Fuse is defective (battery
index: {1:d})
Fuse is defective.
