Siemens 6EP4135-0GB00-0AY0

Technical data
8.7 Mechanical system
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
219
6EP4131-0GB00- ...
(1.2 Ah)
6EP4132-0GB00- ...
(2.5 Ah)
6EP4133-0GB00- ...
(3.2 Ah)
Type of mounting / rail mount-
ing
Yes
Type of mounting /
S7-300 rail mounting
No
Mounting Wall mounting, can be
snapped onto standard
TH35x7,5/15 mounting rails
(EN 60715)
Wall mounting, can be snapped onto standard TH35x15
mounting rails (EN 60715)
Table 8- 7 SITOP UPS1100 7 Ah / 12 Ah
6EP4133-0JB00- ... (5 Ah)
6EP4134-0GB00- ... (7 Ah)
6EP4135-0GB00- ... (12 Ah)
Connection system
Screw-type terminal
Screw-type terminal
Connections / DC input X1-1, X1-2: 1 screw terminal
each for 0.2 - 6 (4) mm² solid
(finely stranded)
X1-1, X1-2: 1 screw terminal each for 0.2 - 16 mm² sol-
id/finely stranded
Connections / signal terminal X2-1, X2-2: 1 screw terminal
each for 0.14 - 4 (2.5) mm²
solid (finely stranded)
X2-1, X2-2: 1 screw terminal each for 0.14 - 4 (2.5) mm²
solid (finely stranded)
Width of the housing
189 mm
186 mm
253 mm
Height of the housing
186 mm
186 mm
186 mm
Depth of the housing
112.7 mm
110.3 mm
110 mm
Installation width
189 mm
186 mm
253 mm
Mounting height
201 mm
201 mm
201 mm
Weight, approx.
3.4 kg
6.1 kg
9.3 kg
Product feature /
of the housing /
housing that can be lined up
next to one another
Yes
Type of mounting /
wall mounting
Yes
Type of mounting /
rail mounting
Yes
Type of mounting /
S7-300 rail mounting
No
Mounting Wall mounting, can be
snapped onto standard
TH35x15 mounting rails
(EN 60715)
Wall mounting
