Siemens 6EP4135-0GB00-0AY0

Description, device design, dimension drawing
2.3 Operator controls
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
27
Changes are also effective in the buffer mode.
Table 2- 1 With interface (up to firmware release less than V1.20)
Rotary coding
switch,
buffer time
Rotary coding
switch,
connection thresh-
old
Wire jumper
ON/OFF with respect to -
Result
OFF
21 - 25
Yes
Buffering not permitted
0,5 - MAX 21 - 25 Yes Buffer mode permitted
(buffer time corresponding
to the settings or maxi-
mum buffer time)
OFF, 0,5 - MAX
21 - 25
No
Buffering not permitted
OFF, 0,5 - MAX REN Not relevant The software settings
apply
Table 2- 2 With interface (from firmware release V1.20 up to V2.0.x)
Rotary coding
switch,
buffer time
Rotary coding
switch,
connection thresh-
old
Wire jumper
ON/OFF with respect to -
Result
OFF
21 - 25
Yes
Buffering not permitted
0,5 - MAX 21 - 25 Yes Buffer mode permitted
(buffer time corresponding
to the settings or maxi-
mum buffer time)
OFF, 0,5 - MAX
21 - 25, REN
No
Buffering not permitted
OFF, 0,5 - MAX REN Yes The software settings
apply
Table 2- 3 With interface (from firmware release V2.1)
Rotary coding
switch
buffer time
Rotary coding
switch
switch-in threshold
Wire jumper
ON/OFF with respect to -
Result
OFF
21 - 25
Yes
Buffering not permitted
0,5 - MAX
21 - 25
No
Buffering not permitted
0,5 - MAX 21 - 25 Yes Buffer mode permitted
(buffer time corresponding
to the settings or maxi-
mum buffer time)
OFF,
0,5 - MAX
21 - 25 REN No Buffering not permitted
