Siemens 6EP4135-0GB00-0AY0

Engineering and remote access
3.4 SIMATIC STEP 7
SITOP UPS1600 / UPS1100
78 Manual, 04.2017, A5E37775406-8-76
5. Click the desired subgroup.
The subgroup opens.
6. Enter the values.
7. Confirm your entry by clicking on "OK".
The parameters are stored in the project.
Buffer parameters
Parameter
Value range
Default setting
Buffer time
1 … 32767 s
600 s
Additional buffer time after the PC was powered down
1)
1 … 300 s
60 s
Connection threshold
21 … 25 V
22.5 V
Stop buffering voltage
18 ... 23 V
18.5 V
Wait time for stable input voltage
200 … 65,000 ms
1000 ms
Downtime alarm
0 … 20.000 ms
125 ms
Buffering allowed
Yes / No
Yes
Enable reset after buffering
Yes / No
No
1)
valid from V2.0.4 or V2.1
