Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
92 Manual, 04.2017, A5E37775406-8-76
Index
Slot
Subslot
Data set
Type
Description
Data size
0x0008 0 1 Buffering parameters
from V2.0
Reading /
writing
Buffer parameters of the
SITOP UPS1600
2 bytes
0x0009 0 1 Maintenance parame-
ters from V2.1
Reading /
writing
Maintenance parameters of the
SITOP UPS1600
2 bytes
0x0010 0 1 DC-UPS command Writing Sends special commands to the
SITOP UPS1600
4 bytes
0x0010 0 1 Result of DC-UPS
command
Reading Response to the previously sent
"DC-UPS command"
4 bytes
0x0011 0 1 Battery 1 information
parameters
Reading Information regarding the connected
battery module 1 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0012 0 1 Battery 2 information
parameters
Reading Information regarding the connected
battery module 2 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0013 0 1 Battery 3 information
parameters
Reading Information regarding the connected
battery module 3 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0014 0 1 Battery 4 information
parameters
Reading Information regarding the connected
battery module 4 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0015 0 1 Battery 5 information
parameters
Reading Information regarding the connected
battery module 5 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0016 0 1 Battery 6 information
parameters
Reading Information regarding the connected
battery module 6 SITOP UPS1100.
This information is available via the link
"Energy Storage".
68bytes
(from V2.2)
0x0020 0 1 State information Reading Status information about
SITOP UPS1600 and the connected
battery modules SITOP UPS1100.
Information about the SITOP UPS1100
battery modules is available via the link
"Energy Storage".
64 bytes
70 bytes
(from V2.1)
0x0040 0 1 Identification value
parameters
Reading /
writing
Device identification parameters. 80 bytes
108 bytes
(from V2.1)
0x0041 0 1 Web server
parameters
Reading /
writing
Web server settings of the
SITOP UPS1600.
1 byte
6 bytes (from
V2.1)
0x0042 0 1 OPC UA server Reading/
writing
OPC UA settings of the
SITOP UPS1600.
4 bytes (from
V2.2)
0x0043 0 1 NTP client parameters Reading/
writing
Setting for connection to NTP servers 66 bytes
(from V2.2)
