Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
94 Manual, 04.2017, A5E37775406-8-76
0x0002: Battery parameters (reading/writing)
Data
Description
Data type
Battery defect voltage [0.01 V] Battery defect voltage: If the battery voltage falls below the set
value, then the battery is identified to be defective.
Unsigned16
Battery capacity [0.1 Ah] Battery capacity: Total battery capacity of all energy storage de-
vices connected to the
SITOP UPS1600.
Unsigned16
Ignore battery coding Ignore data of the coded battery: When this parameter is set to
"1", then data of the coded battery is ignored. Instead, data is
taken from the parameterization ("Battery Parameters", "Charging
Parameters").
Unsigned8
0x0003: Charging parameters (reading/writing)
Data
Description
Data type
End of charge voltage [0.01 V] End of charge voltage: Battery voltage when charging changes to
trickle charging. The connected energy storage device is then
charged up to 100 %.
Unsigned16
Charge current [1 mA] Charge current: Current magnitude used to charge the connected
battery modules during the constant charging process.
Unsigned16
0x0004: Reset parameters (reading/writing)
Data
Description
Data type
Reset time [1 s] Reset time: Time during which the SITOP UPS1600 output is
shutdown if the connected devices are reset.
Unsigned8
0x0005: Battery information parameters (reading)
Data
Description
Data type
Number of batteries Number of connected battery modules. Here, only the
SITOP UPS1100 battery modules (coded batteries) are counted.
Unsigned8
Fill byte(s)
-
3 x Unsigned8
Batt 1: Standby time [1 s]
Standby time
Unsigned32
Batt 1: Buffer time [1 s] Required buffer time, after which the SITOP UPS1600 shuts down
in the buffer mode.
Unsigned32
Batt 1: Total charging current
[1 mAh]
Total charge level (battery-specific data): Total charge within the
service lifetime of the SITOP UPS1600.
Unsigned32
Batt 1: Total culled current [1 mAh] Total charge level used (battery-specific data): Total discharge
over the lifetime of the SITOP UPS1600.
Unsigned32
Batt 1: EOCV [0.01 V] "End-of-charge voltage": Battery voltage when charging changes
to trickle charging. The energy storage device is then charged up
to 100 %.
Unsigned16
Batt 1: Charge current [1 mA] Charge current: Current magnitude used to charge the connected
battery modules during the constant charging process.
Unsigned16
