Siemens 6RA8018-6DV62

Connecting
6.7 Fuses
SINAMICS DCM DC Converter
154 Operating Instructions, 12/2018, A5E34763375A
Device
3 x phase fuses
Siemens ЯU
3x phase fuses
Siemens ЯU for DCM
packages
3 x phase fuses
Bussmann ЯU
3 x phase fuses
Bussmann ЯU
Article
number
I/U
[A/V]
Article
number
I/U
[A/V]
Article
number
I/U [A/V]
Order No.
I/U [A/V]
Order No.
I/U [A/V]
6RA8078-
6FV62-0AA0
280 /
480
3NE3231 350 /
1000
3NE3231 350 /
1000
170M3167 315 /
660
FWH-275A 275 /
500
6RA8082-
6FV62-0AA0
450 /
480
3NE3233 450 /
1000
3NE3333 450 /
1000
170M3170 450 /
660
FWH-450A 450 /
500
6RA8085-
6FV62-0AA0
600 /
480
3NE3336 630 /
1000
3NE3336 630 /
1000
170M4167 700 /
660
FWH-600A 600 /
500
6RA8087-
6FV62-0AA0
850 /
480
3NE3338-8 800 /
800
3NE3338-8 800 /
800
170M5165 900 /
660
FWH-800A 800 /
500
It is not permissible to use different fuse types together.
Table 6- 18 DC fuse
Device
1 x DC fuse
Siemens ЯU
1 x DC fuse
Bussmann ЯU
Article number
I/U [A/V]
Article number
I/U [A/V]
Order No.
I/U [A/V]
6RA8013-6FV62-0AA0
15 / 480
3NE1814-0
20 / 690
FWP-35B
35 / 660
6RA8018-6FV62-0AA0
30 / 480
3NE4102
40 / 1000
FWP-35B
35 / 660
6RA8025-6FV62-0AA0
60 / 480
3NE4120
80 / 1000
FWP-70B
70 / 660
6RA8028-6FV62-0AA0
90 / 480
3NE4122
125 / 1000
FWP-125A
125 / 660
6RA8031-6FV62-0AA0
125 / 480
3NE4124
160 / 1000
FWP-150A
150 / 660
6RA8075-6FV62-0AA0
210 / 480
3NE3227
250 / 1000
FWP-250A
250 / 660
6RA8078-6FV62-0AA0
280 / 480
3NE3231
350 / 1000
FWP-350A
350 / 660
6RA8082-6FV62-0AA0
450 / 480
3NE3334-0B
500 / 1000
FWP-500A
500 / 660
6RA8085-6FV62-0AA0
600 / 480
3NE3336
630 / 1000
FWP-700A
700 / 660
6RA8087-6FV62-0AA0
850 / 480
3NE3334-0B
1)
500 / 1000
FWP-1000A
1000 / 660
1)
Two fuses connected in parallel
FWH-... and FWP-... fuses are mechanically incompatible with 3NE... and 170M... fuses.
It is not permissible to use different fuse types together.
Table 6- 19 Arm fuses
Device
Siemens ЯU arm fuses
Article number
I/U [A/V]
Qty
Article number
I/U [A/V]
6RA8091-6FV62-0AA0
1200 / 480
6
3NE3338-8
800 / 800
The arm fuses are included in the device. No external semiconductor fuses are required.
It is not permissible to use different fuse types together.
