Connecting
6.9 Assignment of terminals and connectors
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
183
DRIVE-CLiQ
Table 6- 40 DRIVE-CLiQ connector assignment
Connector
X100, X101
Pin
Signal name
Technical specifications
1
TXP
Transmit data +
2 TXN Transmit data -
3
RXP
Receive data +
4
-
Reserved, do not use
5
-
Reserved, do not use
6
RXN
Receive data -
7
-
Reserved, do not use
8
-
Reserved, do not use
-
Shield
Permanently connected to ground
"Advanced CUD" module
Parallel interface
Table 6- 41 Connector assignment, parallel interface
Connector
X165, X166
Pin
Signal name
Technical specifications
1
SYNC_P
Synchronization +
2
SYNC_N
Synchronization -
3
CANH
CAN +
4
-
Reserved, do not use
5
-
Reserved, do not use
6
CANL
CAN -
7
-
Reserved, do not use
8
-
Reserved, do not use
-
Shield
Permanently connected to ground
Standard CUD, Advanced CUD module
