Siemens 6RA8018-6DV62

Additional system components
7.6 Terminal Module TM150
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
267
7.6.9
Technical data
Table 7- 50 Technical data
6SL3055-0AA00-3LA0
Unit
Value
Voltage
Current (without DRIVE-CLiQ)
Power loss
V
DC
A
DC
W
24 V DC (20.4 - 28.8)
0.07
1.6
PE/ground connection On enclosure with M4/1.8 Nm screw
Maximum cable length
m
50
Ventilation clearances, above/below
mm
50
Weight
kg
Note
In order to guarantee the degree of protection, all of the connectors must be correctly
screwed into place and appropriately locked.
