10.3 Communication according to PROFIdrive
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
451
Evaluate parameter response
Parameter response
Offset
Response header Request reference mirrored =
25 hex
Response ID = 01 hex 0 + 1
Axis mirrored = 02 hex
Number of parameters = 01 hex
2 + 3
Parameter value
Format = 06 hex
Number of values = 08 hex
4 + 5
1st value = 1355 dec 6
2nd value = 0 dec
8
...
...
8th value = 0 dec
20
Information about the parameter response:
● Request reference mirrored:
This response belongs to the request with request reference 25.
● Response ID:
01 hex → Read request positive, values stored as of 1st value.
● Axis mirrored, number of parameters:
The values correspond to the values from the request.
● Format:
06 hex → Parameter values are in the unsigned16 format.
● Number of values:
08 hex → Eight parameter values are available.
● 1st value ... 8th value
A fault is only entered in value 1 of the fault buffer for drive 2.
