Descriptions of functions
10.28 Connecting units in parallel and in series
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
613
Parameter assignment
The following parameters should be specifically set for operation with this converter
topology:
Table 10- 72 Parameter assignment, 6-pulse series connection
Parameter
Master
Slave or parallel units
p51799
Operating principle
0, 31 or 32
The same as at the master
p51800 Position in the topology 31 (Master) 32 (slave)
33 (parallel to the master)
34 (parallel to the slave)
p51801
Number of send data
Any
Any
p51802 Minimum number of nodes Number of SINAMICS DCM units
in this topology
Number of SINAMICS DCM units
in this topology
p51803
n+m mode
0
0
p51804[..]
Transmit data
Any
Any
p51805
Bus terminator
0 or 1
1)
0 or 1
1)
p51806
Station address
Unique address
Unique address
p51807
Telegram failure time
0.1 s
0.1 s
p50082
Field operating mode
≠ 0
0 (no field)
p50076[..]
Reduction in rated unit DC current
-
The same as at the master
p50078[..]
Rated value for supply voltage
-
The same as at the master
p50100
Rated motor current
-
The same as at the master
p50110
Armature resistance Ra
2)
-
The same as at the master
p50111
Armature inductance La
2)
-
The same as at the master
p50114
Motor thermal time constant
Motor thermal time constant in s
The same as at the master
p50140 Motor I
2
t monitoring, response
when starting
Application-specific The same as at the master
p51591
La reduction factor
2)
-
The same as at the master
1)
= 1 at the two outermost units (= at the physical ends of the bus line)
= 0 on all of the other units
2)
The optimization run for current controller and precontrol (p50051 = 23 or 25) sets the correct values for these
parameters.
