Siemens 6RA8018-6DV62

Technical data
4.5 Unit data
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
65
Table 4- 32 Technical data for 3-ph. 480 V AC, 125 A to 280 A, 4Q devices
Article number 6RA80 ..
..31-6FV62-...
..75-6FV62-...
..78-6FV62-...
Rated DC current
A
125
210
280
Rated armature input current
2)
A
104
174
232
Rated power
kW
62.5
105
140
Power loss at
rated DC current (approx.)
W
431
720
811
Rated field DC current
A
10
15
15
Type of cooling
Self-ventilated
Forced ventilation
Forced ventilation
Rated
fan supply voltage
V
-
Fan with internal
power supply
Fan with internal
power supply
Fan air flow
m
3
/h
-
300
300
Fan noise level
dB(A)
-
70.3
70.3
Dimensions (WxHxD)
mm
268x385x252
268x385x252
268x385x252
Weight (approx.)
kg
14
15
15
Rated DC voltage for single-phase
operation
V
335
-
-
Rated DC current for
single-phase operation
A
87.5
-
-
Table 4- 33 Technical data for 3-ph. 480 V AC, 450 A to 1200 A, 4Q devices
Article number 6RA80 ..
..82-6FV62-...
..85-6FV62-...
..87-6FV62-...
..91-6FV62-...
Rated DC current
A
450
600
850
1200
Rated armature input current
2)
A
374
498
706
996
Rated power
kW
225
300
425
600
Power loss at
rated DC current (approx.)
W
1583
1909
2597
4237
Rated field DC current
A
25
25
30
40
Type of cooling
Forced
ventilation
Forced
ventilation
Forced
ventilation
Forced
ventilation
Rated fan supply voltage
50 Hz
V
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±10%)
clockwise phase
sequence
60 Hz
V
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
V
With option L21: 1-ph. 230 V AC (±10%)
Rated fan current
50 Hz
60 Hz
A
0.27
0.33
0.27
0.33
0.27
0.33
0.38
0.5
Rated fan current
with option L21
50 Hz
60 Hz
A
0.68
0.95
0.68
0.95
0.68
0.95
1.16
1.7
Fan air flow
m
3
/h
600
600
600
1000
Fan noise level
50 Hz
60 Hz
dB(A)
70.3
74.4
70.3
74.4
70.3
74.4
70.4
74.2
Dimensions (WxHxD)
mm
268x625x275
268x625x275
268x700x311
268x785x435
Weight (approx.)
kg
31
31
42
78
