Functional safety
13.9 Circuit breakers and power contactors
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
723
13.9
Circuit breakers and power contactors
6RA8013_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
15
-
-
-
Rated supply voltage
armature [V]
400
480
- - -
Contactor armature circuit
-
Main contactor designed for AC1, 40 A
Siemens
3RT2023-2AL20
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8018_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
30
-
-
-
Rated armature supply
voltage [V]
400
480
- - -
Contactor armature circuit
-
Main contactor designed for AC1, 40 A
Siemens
3RT2023-2AL20
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8025_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
60
-
-
-
Rated armature supply
voltage [V]
400
480
575
- - -
Contactor armature circuit
-
Main contactor designed for AC1, 50 A
Siemens
3RT1035-3AL20
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8028_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
90
-
-
-
Rated armature supply
voltage [V]
400
480
- - -
Contactor armature circuit
-
Main contactor designed for AC1, 100 A
Siemens
3RT1044-3AL20
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8031_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
125
-
-
-
Rated armature supply
voltage [V]
400
480
575
- - -
Contactor armature circuit
-
Main contactor designed for AC1, 120 A
Siemens
3RT1446-1AL20
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
