SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
747
Designation
Function
Typ.
runtime
Group
RDP
Reading drive parameters (REAL type)
14
System
RDP_D Reading drive parameters (DOUBLE type) 14
RDP_I
Reading drive parameters (INTEGER type)
15
RDP_UD Reading drive parameters (UNSIGNED
DOUBLE INTEGER type)
15
RDP_UI Reading drive parameters (UNSIGNED
INTEGER type)
16
RDP_US Reading drive parameters (UNSIGNED
SHORT INTEGER type)
15
SAH
Sample and hold (REAL type)
23
SAH_B
Sample and hold (BOOL type)
23
SAH_BY
Sample and hold (BYTE type)
24
SAH_D
Sample and hold (DOUBLE type)
24
SAH_I
Sample and hold (INTEGER type)
24
SAV
Value buffering (REAL type)
5
SAV_BY
Value buffering (BYTE type)
6
SAV_D
Value buffering (DOUBLE type)
6
SAV_I
Value buffering (INTEGER type)
6
STM
Fault/alarm trigger
41
WRP
Writing drive parameters (REAL type)
17
WRP_D
Writing drive parameters (DOUBLE type)
13
WRP_I
Writing drive parameters (INTEGER type)
17
WRP_UD Writing drive parameters (UNSIGNED
DOUBLE INTEGER type)
18
WRP_UI Writing drive parameters (UNSIGNED
INTEGER type)
16
WRP_US Writing drive parameters (UNSIGNED
SHORT INTEGER type)
17
DCA
Diameter calculator
16
Technology
INCO
Axial winder moment of inertia
51
TTCU
Winding characteristic
25
OCA
Software cam group
8
WBG
Wobble generator
50
