Siemens CU240B-2 Hardware Installation Manual

Accessories
7.3 Braking Resistor
Power Module PM240
Hardware Installation Manual, 07/2009, A5E00807525B AD
117
Resistor for Power Module ... FSA FSB FSC FSD
Nominal power (HO) of the
Power Module
0.37 kW ...
1.5 kW
2.2 kW ... 4 kW 5.5 kW ...
11 kW
15 kW ... 22 kW
Order number 6SE6400-
4BD11-0AA0
6SE6400-
4BD12-0BA0
6SE6400-
4BD16-5CA0
6SE6400-
4BD21-2DA0
Thermoswitch (NC contact)
maximum contact load
connecting cable
250 V
AC
/ 2.5 A 250 V
AC
/ 2.5 A 250 V
AC
/ 2.5 A 250 V
AC
/ 2.5 A
Weight 1.0 kg 1.6 kg 3.8 kg 7.4 kg
Table 7- 27 Technical specifications, braking resistors, Part 2
Resistor for Power Module ... FSE FSF FSGX
Nominal power (HO) of the
Power Module
30 kW ...
37 kW
45 kW ...
75 kW
90 kW ...
110 kW
132 kW ...
200 kW
Order number 6SE6400-
4BD22-2EA0
6SE6400-
4BD24-0FA0
6SE6400-
4BD26-0FA0
6SL3000-
1BE32-5AA0
Resistance 15 Ω 8.2 Ω 5.5 Ω 2.2 Ω
Rated power P
DB
2.2 kW 4.0 kW 6.0 kW 50 kW
Peak power P
max
44 kW 80 kW 120 kW 300 kW
Degree of protection IP20 or IPXXB IP20 or IPXXB IP20 or IPXXB IP20
Power Connections M6 studs M6 studs M6 studs M10 bolt-type
screw terminal
Thermoswitch (NC contact)
maximum contact load
connecting cable
250 V
AC
/ 2.5 A 250 V
AC
/ 0.2 A 250 V
AC
/ 0.2 A 250 V
AC
/ 10 A
Weight 10.6 kg 16.7 kg 21 kg 120 kg
