Service and
maintenance
5.2 Replacing compo
nents
Power Module PM240
Hardware Installation Manual, 07/2009, A5E00807525B AD
55
Replacing the cooling fan FSGX
Preparatory steps
●
Disconnect the chassi
s un
it from the power supply.
●
Allow unimpeded access.
●
Remove the protective cover.
1
2
Figure 5-4
Fan r
eplacement, Power Module FSGX
54
56
