Accessories
7.1 Reactor and filter
Power Module PM240
Hardware Installation Manual, 07/2009, A5E00807525B AD
91
Table 7- 10 Technical specifications of the output reactors (table 1 of 6)
Suitable for Power Module with rated power (HO) of
0.37 kW ... 1.5 kW 2.2 kW … 4 kW 5.5 kW … 11 kW
Feature
FSA FSB FSC
MLFB of the line reactor 6SE6400-3TC00-4AD2 6SL3202-0AE21-0CA0 6SL3202-0AJ23-2CA0
MLFB of the suitable Power
Module
6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE22-2 . A0
6SL3224-0BE23-0 . A0
6SL3224-0BE24-0 . A0
6SL3224-0BE25-5 . A0
6SL3224-0BE27-5 . A0
6SL3224-0BE31-1 . A0
Power loss at 50/60 Hz 5 W 20 W 60 W
Motor connection Screw terminals 6 mm²
Connection to Power
Module
Cable, 300 mm length Cable, 400 mm length Cable, 350 mm length
Degree of protection IP00
Overall dimensions
Width
Height
Depth
75.5 mm
200 mm
110 mm
154 mm
270 mm
70 mm
189 mm
334 mm
80 mm
Fixing dimensions
Width
Height
56 mm
187 mm
120 mm
200 mm
156 mm
232 mm
Fixing screw 4 × M4 4 × M5
Weight 2 kg 4.5 kg 9 kg
Possible as base
component
yes
Table 7- 11 Technical specifications of the output reactors (table 2 of 6)
Suitable for Power Module with rated power (HO) of
15 kW 18.5 kW 22 kW
Feature
FSD
MLFB of the line reactor 6SE6400-3TC05-4DD0 6SE6400-3TC03-8DD0 6SE6400-3TC05-4DD0
MLFB of the suitable Power
Module
6SL3224-0BE31-5 . A0 6SL3224-0BE31-8 . A0 6SL3224-0BE32-2 . A0
Power loss at 50/60 Hz 200 W 200 W 200 W
Motor connection Flat connector for M6 cable lug
Connection to Power
Module
Flat connector for M6 cable lug
Degree of protection IP00
Overall dimensions
Width
Height
Depth
225 mm
210 mm
150 mm
