5.9 Function block FB283
Overview
The function block FB283 is an interface block that connects a converter with basic positioner
to a SIMATIC S7 controller via PROFIBUS/PROFINET.
The block FB283 transfers all of the required process data to and from the drive. It is suitable for
both controlling the basic positioner and for a pure speed-controlled drive.
The FB283 additionally provides the following functions:
• Reading and writing parameters in the converter.
• Reading out the fault bu󹪜er of the converter.
• Transferring up to 16 traversing blocks when a function is initiated.
• Reading or writing a maximum of any 10 parameters with one job, e.g. for product
adaptation.
You can 󹪝nd additional information about FB283 in the Internet:
FB283 (http://support.automation.siemens.com/WW/view/en/25166781)
PROFIdrive interface
5.9 Function block FB283
Basic positioner
Function Manual, 09/2020, FW V4.7 SP13, A5E34257659B AG 33
