Parameter Description
r9714 Speed diagnostics [rpm]
[0] Load-side speed actual value
Electrical speed of the motor. For induction motors, the mechanical speed is ob‐
tained from the electrical speed and slip.
[1] Actual SAM/SBR speed limit
r9722.1 1 signal: SS1 active
r9723.16 1 signal: SAM/SBR active
p1226 Standstill detection, speed threshold (Factory set‐
ting: 20 rpm)
The inverter switches off the motor
torque if the speed either fulfills the
condition for standstill detection or
the shutdown speed p9569 has
been reached.
p1227 Standstill detection monitoring time (Value de‐
pends on the power unit)
5.12.6 Setting SLS
5.12.6.1 Setting the monitoring functions
Requirement
You are online with STARTER or Startdrive.
Commissioning
5.12 Setting extended functions
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD 183
