List of Parameters
Parameters
1-353
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the delay time for the safe pulse suppression after STOP B.
In the case of encoderless motion monitoring functions with brake ramp monitoring (p9506 = 1), the parameter has
no effect.
Dependency: Refer to: p9560
Refer to: C01701
Description: Sets the maximum time for the acceptance test mode.
If the acceptance test mode takes longer than the selected time limit, then the mode is automatically terminated.
Dependency: Refer to: C01799
Description: Sets the time interval for carrying out the forced checking procedure and testing the safety motion monitoring func-
tions integrated in the drives.
Within the parameterized time, the safety functions must have been tested at least once (including de-selection of
the "STO" function).
This monitoring time is reset each time the test is carried out.
The signal source to initiate the forced checking procedure is set in p9705.
Dependency: Refer to: p9705
Refer to: A01697, C01798
Note: STO: Safe Torque Off
Description: Sets the shutdown speed for the pulse suppression.
Below this speed "standstill" is assumed and for STOP B, the pulses are suppressed by changing to STOP A).
Dependency: Refer to: p9556
p9556 SI Motion pulse suppression delay time (processor 1) / SI Mtn IL t_del P1
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: C(95) Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0.00 [ms] 600000.00 [ms] 600000.00 [ms]
p9558 SI Motion acceptance test mode time limit (processor 1) / SI Mtn acc t P1
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: C(95) Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
5000.00 [ms] 100000.00 [ms] 40000.00 [ms]
p9559 SI Motion forced checking procedure timer (processor 1) / SI Mtn dyn timer
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: C(95) Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0.00 [h] 9000.00 [h] 8.00 [h]
p9560 SI Motion pulse suppression shutdown speed (processor 1) / SI Mtn IL v_sh P1
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: C(95) Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
10.00 [rpm] 6000.00 [rpm] 10.00 [rpm]
