Setpoint channel

Function diagrams

2-577

SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011

Fig. 2-75 3040 – Direction limitation and direction reversal

- 3040 -

Function diagram

87654321

FP_3040_97_53.vsd

Setpoint channel

G120 CU240B/E-2

13.12.2010 V4.4

Direction limitation and direction reversal

[3030.8] [3050.1]

-1

[2505.2]

p1110

[2505.2]

p1111

[2505.2]

p1113

n_set_1

STW setpoint chan

r1198

.11

1 = Direction reversal

STW setpoint chan

r1198

1 = Inhibit negative direction of

rotation

STW setpoint chan

r1198

1 = Inhibit positive direction of

rotation

n_limit setp

0.000 ... 210000.000 [1/min]

p1063 [D] (210000.000)

r1114

Setp after limit [1/min]
