Siemens CU240S PN-F - PM250 Power Module Dependent Technical Data

Technical data
8.6 Power-dependent technical data, PM250 Power Modules
CU240S and CU240E Control Units, FW 3.2
234 Operating Instructions, 03/2009, A5E02440075B AA
8.6 Power-dependent technical data, PM250 Power Modules
PM250 Power Module
Table 8- 6 PM250 Frame Size C and D
Order No. 6SL3225-
0BE25-5AA0
6SL3225-
0BE27-5AA0
6SL3225-
0BE31-1AA0
6SL3225-
0BE31-5AA0
6SL3225-
0BE31-8AA0
6SL3225-
0BE32-2AA0
Power rating for
HO base load
5.5 kW
7.5 PS
7.5 kW
10.0 PS
11.0 kW
15 PS
15.0 kW
20 PS
18.5 kW
25 PS
22.0 kW
30 PS
Input current for
HO base load
13.2 A 19.0 A 26.0 A 30.0 A 36.0 A 42.0 A
Output current for
HO base load
13.2 A 19.0 A 26.0 A 32.0 A 38.0 A 45.0 A
Input current for
LO base load
18.0 A 25.0 A 32.0 A 36.0 A 42.0 A 56.0 A
Output current for
LO base load
18.0 A 25.0 A 32.0 A 38.0 A 45.0 A 60.0 A
Fuse 20 A 32 A 35 A 50 A 63 A 80 A
Heat loss Available soon Available soon Available soon 0.44 kW 0.55 kW 0.72 kW
Cooling air
requirement
38 l/s
0 CFM
38 l/s
80 CFM
38 l/s
80 CFM
22 l/s
46 CFM
22 l/s
46 CFM
39 l/s
82 CFM
Cable cross-
section for line and
motor connections
2.5 … 10 mm²
14 … 8 AWG
4 … 10 mm²
12 … 8 AWG
6 … 10 mm²
10 … 8 AWG
10 … 35 mm²
7 … 2 AWG
10 … 35 mm²
7 … 2 AWG
16 … 35 mm²
5 … 2 AWG
Weight 7.5 kg / 17 lb 7.5 kg / 17 lb 7.5 kg / 17 lb 15 kg / 33 lb 15 kg / 33 lb 16 kg / 35 lb
Table 8- 7 PM240 Frame Size E and F
Order No. 6SL3225-0BE33-
0AA0
6SL3225-0BE33-
7AA0
6SL3225-0BE34-
5AA0
6SL3225-0BE35-
5AA0
6SL3225-0BE37-
5AA0
Power rating for
HO base load
30.0 kW / 40 PS 37.0 kW / 50.0 PS 45.0 kW / 60 PS 55.0 kW / 75 PS 75 kW / 100 PS
Input current for
HO base load
56 A 70 A 84 A 103 A 135 A
Output current for
HO base load
60 A 75 A 90 A 110 A 145 A
Input current for
LO base load
70 A 84 A 102 A 190 A 223 A
Output current for
LO base load
75 A 90 A 110 A 145 A 178 A
Fuse 100 A 125 A 160 A 200 A 250 A
Heat loss 1 kW 1.3 kW 1.5 kW 2 kW 2.4 kW
Cooling air
requirement
22 l/s / 46 CFM 39 l/s / 82 CFM 94 l/s / 200 CFM 94 l/s / 200 CFM 117 l/s / 250 CFM
Cable cross-
section for line and
motor connections
25 … 35 mm²
3 … 2 AWG
25 … 35 mm²
3 … 2 AWG
35 … 150 mm²
2 … - 5 AWG
70 … 150 mm²
- 2 … - 5 AWG
95 … 150 mm²
- 3 … - 5 AWG
Weight 21 kg / 46 lb 21 kg / 46 lb 51.0 kg / 112 lb 51.0 kg / 112 lb 51.0 kg / 112 lb
