Using the Command Interface
75
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
Table 3-5 Error Coding
DONE
ERROR STATUS Meaning
1 0 0000H Job completed without error
0 1 8090H Address in LADDR invalid
0 1 8092H A type other than BYTE is specified in the ANY reference.
0 1 8093H This SFC is not permitted for the module selected with
LADDR and IOID. (S7-300 modules are permitted for
S7-300, S7-400 modules for S7-400, S7-DP modules for
S7-300 and S7-400.)
0 1 80A0H Negative acknowledgment when reading from AS-i master.
0 1 80A1H Negative acknowledgment when writing to AS-i master
0 1 80A2H DP protocol error at Layer 2
0 1 80A3H DP protocol error involving user interface/user
0 1 80A4H Communication problems on K bus
0 1 80B0H AS-i master does not recognize the data record
0 1 80B1H Specified data record length incorrect
0 1 80B2H The configured slot is not in use.
0 1 80B3H Actual module type does not match the expected module
type in SDB1
0 1 80C0H Data record cannot be read
0 1 80C1H The specified data record is currently being processed
0 1 80C2H There is a job pileup
0 1 80C3H Resource (memory) in use
0 1 80C4H Communication error
0 1 80C5H Distributed I/Os not available
0 1 80C6H Data record transfer aborted due to priority class abort
(warm restart or background) of the distributed I/Os.
0 0 8181H Job active (no error)
0 1 8182H ID following warm restart (STARTUP=TRUE)
0 1 8184H Data type of the RECV formal parameter illegal
0 1 8381H The AS-i slave address is incorrect
0 1 8382H The AS-i slave is not activated (not in LAS).
0 1 8383H Error on the AS-Interface
0 1 8384H Command not permitted in the current status of the AS-i
master.
0 1 8385H An AS-i slave with address 0 exists.
8386H The AS-i slave has illegal configuration data (I/O or ID
codes).
0 1 83A1H The addressed AS-i slave was not found on the
AS-Interface.
0 1 83A2H An AS-i slave with address 0 exists.
