8.2 Connection module Basic PN
Safety
Safety class III according to IEC 60536
Degree of protection accord‐
ing to EN 60529
IP54
Approvals CE / cULus
Electrical data
Input voltage 24 VDC (via X3 connector)
Current carrying capacity Enabling button contacts (X20 connector) max. each 0.5 A / 2-chan‐
nel
Emergency stop button contacts (X21 con‐
nector)
max. each 0.5 A / 2-chan‐
nel
Max. power consumption Connection module without external loading 0.3 A
Panel (HT 8) 1.6 A
5 status signals (X7 and X21) 2.5 A (0.5 A each)
Total: 4.4 A
Max. total
power consumption
105.6 W
Mechanical data
Dimensions Height (without holder for termi‐
nating connector):
66 mm
Width:
165 mm
Length:
166 mm
Weight 0.75 kg
Fall height, max. 1.20 m
Note
Information about the climatic and mechanical environmental conditions is contained in the
associated section under:
"General notes and interconnection" → "Operational planning".
Technical specifications
8.2 Connection module Basic PN
Handheld Terminal HT 8
142 Manual, 07/2015, A5E36371621B-AB
