8.3 PN terminal box
General data
Weight without packaging Approx. 700 g
Degree of protection according to EN 60529 IP65 (with connected HT 8 or with inserted blanking cover)
Electrical data
Rated voltage
Range, permissible
+24 V DC
20.4 to 28.8 V (–15%, +20%)
Transients, maximum permissible 35 V (500 ms)
Time between two transients, minimum 50 s
Current consumption of PN terminal box without HT 8
● Typical
● Continuous current, maximum
● Inrush current I
2
t
● Approx. 100 mA
● Approx. 150 mA
● Approx. 0.5 A
2
s
Current consumption of PN with HT 8, typical Approx. 550 mA
Fuse, internal Electronic
Current load PLC-accompanying signals Max. 100 mA
Note
Recovery time
Wait for approximately one second after withdrawing the connecting cable from the connection
box before reinserting.
After power failures lasting less than one second the connecting cable has to be disconnected.
Technical specifications
8.3 PN terminal box
Handheld Terminal HT 8
Manual, 07/2015, A5E36371621B-AB 143
