IE/PB LINK PN IO
Operating Instructions, 11/2017, C79000-G8976-C393-02
77
Technical data
6
6.1
Technical specifications of the LINK
Table 6- 1 Technical specifications
Technical specifications
Attachment to Industrial Ethernet
Amount 1 x PROFIBUS interface
1 x PROFINET interface with 2port switch
Design of the PROFIBUS interface
Connector
9-pin D-sub female connector
Transmission rate 9,6 / 19,2 / 45,45 / 93,75 / 187,5 / 500 Kbps
1,5 / 3 / 6 / 12 Mbps
Design of PROFINET interface (2port
switch)
Connector
2 x RJ-45 jacks
Transmission rate
10 / 100 Mbps
When working with PROFINET IO and
cyclic transfer, the transmission speed of
100 Mbps full duplex is mandatory.
Aging time
5 minutes
Special features of the ports X1 P1 R
and X1 P2 R
Integration in ring topology / MRP possible
Electrical data
External power supply, redundant
setup
Power supply
Permitted range
24 VDC
+20.4 V to +28.8 V
Current consumption From external power supply
• 200 mA typical (without connected bus
adapter)
• 300 mA maximum
Effective power loss
Typical
4.8 W
Maximum
7.2 W
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 °C to +60 °C
During operation with the rack in-
stalled vertically
0 °C to +40 °C
During storage
-40 °C to +70 °C
During transportation
-40 °C to +70 °C
Relative humidity
During operation
≤ 95 % at 25 °C, no condensation
Operating altitude During operation ≤ 2000 m above sea level at max. 60 °C
ambient temperature
Contaminant concentration
Acc. to ISA-S71.04 severity level G1, G2, G3
Design, dimensions and weight
