Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
127/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
HomePos Setting the home positions for firing on gas Service x x
HomePosGas Home position of fuel damper (gas) 0..90° Service 0° x x
HomePosAir Home position of air damper (gas) 0..90° Service 0° x x
HomePosAux Home position of auxiliary damper (gas) 0..90°
0..100%
Service 0° x x
HomePosAux2 Home position of auxiliary damper 2 0..90° Service 0° x
HomePosAux3 Home position of auxiliary damper 3 0..90° Service 0° x
HomePosVSD Home position of VSD 0..100% Service 0° x
PrepurgePos Setting the prepurge positions for firing on gas Service x x
PrepurgePosAir Prepurge position of air damper (gas) 0..90° Service 90° x x
PrepurgePosAux Prepurge position of auxiliary damper (gas) 0..90°
0..100%
Service 90° x x
PrepurgePosAux
2
Prepurge position of auxiliary damper 2 0..90° Service 90° x
PrepurgePosAux
3
Prepurge position of auxiliary damper 3 0..90° Service 90° x
PrepurgePosVS
D
Prepurge position of VSD 0..100% Service 100% x
IgnitionPos Setting the ignition positions for firing on gas Service x x
IgnitionPosGas Ignition position of fuel damper (gas) 0..90° Service invalid x x
IgnitionPosAir Ignition position of air damper (gas) 0..90° Service invalid x x
IgnitionPosAux Ignition position of auxiliary damper (gas) 0..90°
0..100%
Service invalid x x
IgnitionPosAux2 Ignition position of auxiliary damper 2 0..90° Service invalid x
IgnitionPosAux3 Ignition position of auxiliary damper 3 0..90° Service invalid x
IgnitionPosVSD Ignition position of VSD 10..100% Service invalid x
PostpurgePos Setting the postpurge positions for firing on gas Service x x
PostpurgePosGa
s
Postpurge position of fuel damper (gas) 0..90° Service 15° x x
PostpurgePosAir Postpurge position of air damper (gas) 0..90° Service 15° x x
PostpurgePosAu
x
Postpurge position of auxiliary damper (gas) 0..90°
0..100%
Service 25° x x
