Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
139/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
Remote Mode Operating mode: Remote "off" / remote "on" / W3 Automatic
Burner on
Burner off
User - x x
W3 External setpoint W3, in °C
External setpoint W3, in bar
0..2000 °C
0..100bar
User - x x
Display Contrast User x x
ProductID Displaying the HW version of the AZL User x x
ASN Type reference 1..15 characters User "AZL52.00A
1WH"
x x
ProductionDate Production date 01.01.00..31.12.99
01-01-00..12-31-99
User - x x
SerialNumber Serial number 0..65535 User - x x
ParamSet Code Preselected parameter set: customer code 0..255 User 20 x x
ParamSet Vers Preselected parameter set: version 0..65535 User 400 x x
SW Version SW version of AZL 0..65535 User - x x
Actuators Settings for the actuators User x x
Addressing Addressing unaddressed actuators Service x x
1 AirActuator Actuator to be addressed becomes the air actuator Service x x
2 GasActuat(Oil) Actuator to be addressed becomes the gas actuator, or the
fuel actuator for dual fuel burners with one fuel actuator
Service x x
3 OilActuator Actuator to be addressed becomes the oil actuator Service x x
4 AuxActuator Actuator to be addressed becomes the auxiliary actuator Service x x
5 AuxActuator2 Actuator to be addressed becomes the auxiliary actuator Service x
6 AuxActuator3 Actuator to be addressed becomes the auxiliary actuator Service x
DirectionRot Service x x
DeleteCurves Service x x
1 AirActuator direction of rotation of the respective actuator standard
reversed
OEM standard x x
2 GasActuat(Oil) direction of rotation of the respective actuator standard
reversed
OEM standard x x
3 OilActuator direction of rotation of the respective actuator standard
reversed
OEM standard x x
