Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
138/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
AZL Settings for the display and operating unit User x x
Times AZL-specific time settings User x x
PasswordTime Validity of password 10..480 min OEM 120min x x
Sum/WinterTime Setting the summer-/wintertime Manual
Automatic
User Automatic x x
Time EU/US Setting the summer-/wintertime US/EU S/W time EU
S/W time US
User S/W time
EU
x x
Language Selection of language Deutsch
English
Français
User Deutsch x x
DateFormat Selection of date format (Day.Month.Year or Month-Day-Year) DD.MM.YY
MM-DD-YY
User DD.MM.YY x x
PhysicalUnits User x x
UnitTemperature Selection of display format °C or F Display °C
Display °F
User Display °C x x
UnitPressure Selection of display format bar or psi Display bar
Display psi
User Display bar x x
eBUS User x x
Address E-bus address of LMV 1..8 User 1 x x
SendCycleBU Cycle time for sending the burner control's operating data to
BAS
10..60s User 30s x x
Modbus User x x
Address Modbus address of LMV 1..247 User 1 x x
Baudrate 19200 bit/s
9600 bit/s
User 19200 bit/s x x
Parity Modbus-Parität for LMV no
even
odd
User no x x
Timeout Maximum time with no communication. When this period of
time has elapsed, "Remote" changes to "Local"
0..7200s User 30s x x
Lokal / Remote Change of operating mode local / remote local
remote
User - x x
