Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
137/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
LC_OptgMode Operating mode with load controller ExtLC X5-03
IntLC
IntLC Bus
IntLC X62
ExtLC X62
ExtLC Bus
User IntLC x x
Sensor Select Select actual value input
E1-> Pt100, TL act.
E4-> Pt1000, TL act.
E4-> Ni1000, TL act.
E2-> Temp, TL inact.
E2-> Pressure, TL inact.
E1-> Pt100 for controller + TL and E4-> Pt1000 for TL
E1-> Pt100 for controller + TL and E4-> Ni1000 for TL
No input
Pt100
Pt1000
Ni1000
TempSensor
PressSensor
Pt100Pt1000
Pt100Ni1000
NoSensor
Service Pt100 x x
MeasureRangeP
tNi
End of measurement range for sensor at input X60 150°C/302°F
400°C/752°F
Service 150°C/302°
F
x x
Ext Inp X61 U/I Configuration of external input X61 4..20 mA
2..10 V
0..10 V
Service 0..10 V x x
MRange
TempSens
End of temperature measurement range for input X61 0..2000 °C Service 90°C x x
MRange
PressSens
End of pressure measurement range for input X61 0..99,9 bar Service 2bar x x
Ext Inp X62 U/I Configuration of external input X62 4..20 mA
0/2..10 V
Service 4..20 mA x x
Ext MinSetpoint Accepted preselected minimum external setpoint for X62 / bus 0..100 % ScaleHIcurrent Service 0% x x
Ext MaxSetpoint Accepted preselected maximum external setpoint for X62 / bus 0..100 % ScaleHIcurrent Service 60% x x
Adaption Adapting the controlled system User x x
StartAdaption User x x
AdaptionLoad Adaption load 40..100 % User 100% x x
SW Version SW version of internal load controller 0..65535 User - x x
