Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
136/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
ThreshStage3On Reaction threshold Q3 for switching on stage 3
(integral control deviation * time)
0..1000 User 600 x x
TempLimiter Settings for the temperature limiter function Service x x
TL_ThreshOff Temperature limiter OFF threshold, in °C 0..2000 °C Service 95°C x x
TL_SD_On Temperature limiter switching differential ON -50..0 % TL_Thresh_Off Service -5% x x
ColdStart Settings for the cold start (thermal shock protection) Service x x
ColdStartOn Cold start thermal shock protection, activate/deactivate deactivated
activated
Service deactivated x x
ThresholdOn Cold start thermal shock protection activation level referred to
the current setpoint (Wcurrent)
0..100 % Wcurrent Service 20% x x
StageLoad Cold start thermal shock protection load step 0..100 % Service 15% x x
StageSetp_Mod Cold start thermal shock protection setpoint step (modulating)
referred to the current setpoint (Wcurrent)
1..100 % Wcurrent Service 5% x x
StageSetp_Stag
e
Cold start thermal shock protection setpoint step (multistage)
referred to the current setpoint (Wcurrent)
1..100 % Wcurrent Service 5% x x
MaxTmeMod Cold start thermal shock protection, max. time per step
(modulating)
1..63 min Service 3min x x
MaxTmeStage Cold start thermal shock protection, maximum time per step
(multistage)
1..63 min Service 3min x x
ThresholdOff Cold start thermal shock protection deactivation level referred
to the current setpoint (Wcurrent)
0..100 % Wcurrent Service 80% x x
AdditionalSens Selection for additional sensor (cold start thermal shock
protection)
deactivated
Pt100
Pt1000
Ni1000
Service deactivated x x
Setp AddSensor Setpoint for additional sensor (cold start thermal shock
protection)
0..450°C Service 60°C x x
Release Stages Cold start thermal shock protection load step stage mode no release
release
Service release x x
Configuration General configuration of the load controller User x x
