Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
135/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
ContrlParamLis
t
PID control parameters User x x
StandardParam Selection of standard parameter sets for the load controller Adaption
very fast
fast
normal
slow
very slow
User - x x
P-Part (Xp) Controller parameter proportional band 2..500 % User 15% x x
I-Part (Tn) Controller parameter integral part 0..2000s User 320s x x
D-Part (Tv) Controller parameter differential part 0..1000s User 40s x x
MinActuatorStep Minimum actuator step possible 0,5..10 % User 1% x x
SW_FilterTmeCo
n
Software filter time constant 1..10 s User 3s x x
SetpointW1 Internal setpoint W1, in °C
Internal setpoint W1, in bar
0..2000 °C
0..100bar
User - x x
SetpointW2 Internal setpoint W2, in °C
Internal setpoint W2, in bar
0..2000 °C
0..100bar
User - x x
SD_ModOn Two-position controller switching differential burner ON
modulating referred to the current setpoint (Wcurrent)
-50..+50 % Wcurrent User 1.0% x x
SD_ModOff Two-position controller switching differential burner OFF
modulating referred to the current setpoint (Wcurrent)
0..+50 % Wcurrent User 10% x x
SD_Stage1On Two-position controller switching differential burner ON
multistage referred to the current setpoint (Wcurrent)
-50..+50 % Wcurrent User -2% x x
SD_Stage1Off Two-position controller switching differential stage 1 OFF
referred to the current setpoint (Wcurrent)
0..+50 % Wcurrent User 10% x x
SD_Stage2Off Two-position controller switching differential stage 2 OFF
referred to the current setpoint (Wcurrent)
0..+50 % Wcurrent User 8% x x
SD_Stage3Off Two-position controller switching differential stage 3_1 OFF
referred to the current setpoint (Wcurrent)
0..+50 % Wcurrent User 6% x x
ThreshStage2On Reaction threshold Q2 for switching on stage 2
(integral control deviation * time)
0..1000 User 300 x x
