Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
134/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
Tau Kleinlast Time constant Tau of O2 controller's controlled system with
low-fire
1..27s OEM invalid x
P Volllast P-part of O2 controller with high-fire 3..500 % Service invalid x
I Volllast I-part of O2 controller with high-fire 0..500s Service invalid x
Tau Volllast Time constant Tau of O2 controller's controlled system with
high-fire
1..27s OEM invalid x
O2 CtrlThreshold Minimum load O2 control (oil) 0..100 % Service 0% x
Type of Fuel Selection of type of oil user def
oil EL
oil H
Service oil EL x
Fuel user def Service x
V_LNmin Air volume under standard conditions and lambda = 1 0,00..40,00 Service 11.2 x
V_afNmin Flue gas volume wet under standard conditions and lambda =
1
0,00..40,00 Service 12.02 x
V_atrNmin Flue gas volume dry under standard conditions and lambda =
1
0,00..40,00 Service 10.53 x
A2 Adjustable constant for calculating the combustion efficiency
(oil)
0.40..0.80 Service 0.65 x
B / 1000 Adjustable constant for calculating the combustion efficiency
(oil)
1..20 Service 9 x
O2 Content Air Oxygen content of air 0..30% OEM 20.9% x
Type Air Change Impact of air density change on O2 value like theory
like P air
OEM like theory x
Process Data User x
CombEfficiency 0..200% User - x
ManVar O2 Ctrl -35..35% User - x
Release O2 Ctrl deactivated
activated
User - x
Air-related Load 0..100%, S1, S2, S3 User - x
LoadController Settings for the internal load controller User x x
ControllerPara
m
Setting the controller parameters User x x
