Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
133/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
I High-Fire I-part of O2 controller with high-fire 0..500s Service invalid x
Tau High-Fire Time constant Tau of O2 controller's controlled system with
high-fire
1..27s OEM invalid x
O2 CtrlThreshold Minimum load O2 control (gas) 0..100 % Service 0% x
Type of Fuel Selection of type of gas user def
naturalGasH
naturalGasL
propane
butane
Service naturalGasH x
Fuel user def User-defined setting of the fuel parameters Service x
V_LNmin Air volume under standard conditions and lambda = 1 0,00..40,00 Service 9.90 x
V_afNmin Flue gas volume wet under standard conditions and lambda =
1
0,00..40,00 Service 10.93 x
V_atrNmin Flue gas volume dry under standard conditions and lambda =
1
0,00..40,00 Service 8.89 x
A2 Adjustable constant for calculating the combustion efficiency
(gas)
0.40..0.80 Service 0.65 x
B / 1000 Adjustable constant for calculating the combustion efficiency
(gas)
1..20 Service 9 x
O2 Content Air Oxygen content of air 0..30% OEM 20.9% x
Type
ofAirChange
Impact of air density change on O2 value like theory
like P air
OEM like theory x
OilSettings Parameter settings for firing on oil Service x
OptgMode Operating mode of O2 controller / monitor when firing on oil auto deact
man deact
O2 Limiter
O2 Control
conAutoDeac
Service man deact x
O2 Control Service x
O2 Limiter Service x
Control Param Service x
P Kleinlast P-part of O2 controller with low-fire 3..500 % Service invalid x
I Kleinlast I-part of O2 controller with low-fire 0..500s Service invalid x
