Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
132/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
Times Service x x
OperatRampMod Duration operating ramp ratio control modulating operation 30..120s Service 30s x x
OperatRampSta
ge
Duration operating ramp ratio control multistage operation 10..60s Service 10s x x
TimeNoFlame Duration ramp in prepurge and ignition position 10..120s Service 10s x x
NumFuelActuato
rs
Number of fuel actuators 1..2 OEM 2 x x
ShutdownBehav This parameter determines the way the ratio control system
behaves in the lockout phase
Unchanged
PostpurgeP
HomePos
Service HomePos x x
ProgramStop Program stop deactivated
24 PrePurgP
32 PreP FGR
36 IgnitPos
44 Interv 1
52 Interv 2
72 PostPPos
76 PostPFGR
Service deactivated x x
O2Ctrl/Limiter Parameter settings for O2 control and monitor function User x
GasSettings Parameter settings for firing on gas Service x
OptgMode Operating mode of O2 controller / monitor when firing on gas auto deact
man deact
O2 Limiter
O2 Control
conAutoDeac
Service man deact x
O2 Control Service x
O2 Limiter Service x
Control Param Service x
P Low-Fire P-part of O2 controller with low-fire 3..500 % Service invalid x
I Low-Fire I-part of O2 controller with low-fire 0..500s Service invalid x
Tau Low-Fire Time constant Tau of O2 controller's controlled system with
low-fire
1..27s OEM invalid x
P High-Fire P-part of O2 controller with high-fire 3..500 % Service invalid x
