Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
131/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
IgnitionPosAux Service x x
IgnitionPosAux2 Service x
IgnitionPosAux3 Service x
IgnitionPosVSD Service x
CurveParams Setting the curve parameters of ratio control for firing on oil Service x x
Curve Settings Service x x
Operation Mode Selection of burner operating mode (multistage or modulating)
for oil
Two-stage
Three-stage
Modulating
OEM Modulating x x
LoadLimits Setting the minimum and maximum load limits Service x x
MinLoadOil Minimum load "Low fire" (oil) 0..MaxLoadOil Service 0% x x
MaxLoadOil Maximum load "High fire" (oil) MinLoadOil..100% Service 100% x x
AuxActuator Auxiliary actuator for firing on oil: Deactivate / activate / VSD
operation
deactivated
Damper act
VSD activat
OEM deactivated x
AirActuator Air actuator for firing on oil: Deactivate / activate / air-regulating deactivated
activated
air influen
OEM air influen x
AuxActuator 1 Auxiliary actuator 1 for firing on oil: Deactivate / activate / air-
regulating
deactivated
activated
air influen
OEM deactivated x
AuxActuator 2 Auxiliary actuator 2 for firing on oil: Deactivate / activate / air-
regulating
deactivated
activated
air influen
OEM deactivated x
AuxActuator 3 Auxiliary actuator 3 for firing on oil: Deactivate / activate / air-
regulating
deactivated
activated
air influen
OEM deactivated x
VSD VSD for firing on oil: Deactivate / activate / air-regulating deactivated
activated
air influen
OEM deactivated x
Autom/Manual/O
ff
Selection of manual or automatic operation Automatic
Burner on
Burner off
User Automatic x x
