Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
130/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
PrepurgePosVS
D
Prepurge position of VSD 0..100% Service 100% x
IgnitionPos Setting the ignition positions for firing on oil Service x x
IgnitionPosOil Ignition position of fuel damper (oil) 0..90° Service invalid x x
IgnitionPosAir Ignition position of air damper (oil) 0..90° Service invalid x x
IgnitionPosAux Ignition position of auxiliary damper (gas) 0..90°
0..100%
Service invalid x x
IgnitionPosAux2 Ignition position of auxiliary damper 2 0..90° Service invalid x
IgnitionPosAux3 Ignition position of auxiliary damper 3 0..90° Service invalid x
IgnitionPosVSD Ignition position of VSD 10..100% Service invalid x
PostpurgePos Setting the postpurge positions for firing on oil Service x x
PostpurgePosOil Postpurge position of fuel damper (oil) 0..90° Service 0° x x
PostpurgePosAir Postpurge position of air damper (oil) 0..90° Service 15° x x
PostpurgePosAu
x
Postpurge position of auxiliary damper (oil) 0..90°
0..100%
Service 25° x x
PostpurgePosAu
x2
Postpurge position of auxiliary damper 2 0..90° Service 25° x
PostpurgePosAu
x3
Postpurge position of auxiliary damper 3 0..90° Service 25° x
PostpurgePosVS
D
Postpurge position of VSD 0..100% Service 50% x
ProgramStop Program stop deactivated
24 PrePurgP
32 PreP FGR
36 IgnitPos
44 Interv 1
52 Interv 2
72 PostPPos
76 PostPFGR
Service deactivated x x
ResetIgnitPos Resetting the ignition positions to invalid value Service x x
IgnitionPosOil Service x x
IgnitionPosAir Service x x
