Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
143/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
O2 Sensor Configuration of oxygen sensor no sensor
QGO20
Service no sensor x
SupAirTempSen
s
Configuration of supply air temperature input no sensor
Pt1000
Ni1000
Service no sensor x
FlueGasTempSe
ns
Configuration of flue gas temperature input no sensor
Pt1000
Ni1000
Service no sensor x
MaxTempFlGas
Gas
Switch-off limit of flue gas temperature 0..400°C Service 400°C x
MaxTempFlGas
Oil
Switch-off limit of flue gas temperature 0..400°C Service 400°C x
Displayed
Values
User x
Current O2
Value
Current O2 value 0..100% User - x
SupplyAirTemp Supply air temperature in °C -100..923 °C User - x
FlueGasTemp Flue gas temperature in °C -100..923 °C User - x
QGO
SensorTemp
Sensor temperature of QGO in °C -100..923 °C User - x
QGO
HeatingLoad
Control value of QGO heating in 0.1% 0..100% User - x
QGO Resistance Internal resistance of QGO's Nernst cell 0..1000 Ohm User - x
ProductID User x
ASN Type reference 1..15 characters User "PLL52.110
A200"
x
ProductionDate Date of production 01.01.00..31.12.99
01-01-00..12-31-99
User - x
SerialNumber Serial number 0..65535 User - x
ParamSet Code Preselected parameter set: customer code 0..255 User 20 x
ParamSet Vers Preselected parameter set: version 0..65535 User 400 x
SW Version SW version of O2M 0..65535 User - x
