Siemens LMV51.140C1 Technical Instructions

LMVSeriesTechnicalInstructions 
DocumentNo.LV5‐1000
SCCInc. Page27 Section4


Parameter
 % Value Notes
BoilerSetpointorSetpAddSensor N/A 300
o
F Currentsetpoint
ThresholdOn(%ofcurrentsetpoint) 50 150
o
F
Measuredtemperaturemustgobelow
ThresholdOntoengagecoldstart

ThresholdOff(%ofcurrentsetpoint) 80 240
o
F
Coldstartwillnotdisengageuntil
ThresholdOffismet

StageSetp_Mod(%ofcurrentsetpoint) 80 240
o
F
Definesthenecessarytemperature
changerequiredtotriggeraloadstep

StageLoad 5 N/A Determinesthesizeoftheloadstep
MaxTmeMod N/A 10min
Determinesthemax.timebetweenload
steps





Figure4‐9:ExampleofaTime‐basedSteppingStart



