LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1
52.2
52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
PasswordTime (O) 120min 10-480min Sets the length of time before the password times out.
x x x
Sum/WinterTime (U) Automatic
Manual
Automatic
Manual: Daylight savings time disabled.
Automatic: Daylight savings time enabled.
x x
x
Time EU/US (U)
S/W time
US
S/W time US
S/W time EU
Daylight savings time schedule. US setting starts the first Sunday in April and ends the last
Sunday in October.
x x x
Language (U) English
See
Description
Selects the language for the AZL display. Options are English, Deutsch, Francais, Espagnol,
Italiano or Portuguese.
x x x
DateFormat (U) MM-DD-YY
DD.MM.YY
MM-DD-YY
Selects the date format. Choices: MM-DD-YY (US) or DD.MM.YY (European).
x x x
Params & Display>
AZL
PhysicalUnits (U) F / psi
F / psi
C / bar
Either °C / bar or °F / psi can be chosen.
x x x
Address (U) 1 1-8 Sets the LMV5 address for eBUS (job specific).
x x x
SendCycleBU (U) 30s 10-60s Sets the cycle time for the LMV5 to send data to the BAS (job specific).
x x x
Address (U) 1 1-247 Sets the LMV5 address for Modbus (job specific).
x x x
Baudrate (U) 19200 bit/s
9600 bit/s
19200 bit/s
Sets the baud rate of the Modbus port, which is an RJ45 jack located on the underside of the
AZL. Also affects data output. NOTE: To use Modbus, it must be activated at: Operation >
OptgModeSelect .
x x x
Parity (U) no
odd
This sets the parity of the Modbus port. Also affects data output.
x x x
Timeout (U) 30s 0-7200s
If no communication occurs for this period, the AZL considers the Modbus to be unavailable.
If the AZL considers the Modbus to be unavailable, then it will make setpoint W1 the current
setpoint. Other Modbus values will remain what they were previously and / or be
overwritten by input through the AZL.
x x x
Local / Remote (U) local
local
remote
This enables or disables the use of a Modbus conveyed setpoint, setpoint W3.
Local - W3 will not be observed.
Remote - if there is no timeout condition and the remote operating mode is automatic, then
setpoint W3 will be observed.
x x x
Remote Mode (U) View the Modbus remote mode status: Automatic, Manual, Burner off
x x x
W3 (U) 32 F
32-3632 F
0-1449 PSI
W3 is the Modbus conveyed setpoint. Use with operating mode IntLC Bus.
x x x
Read Only
Params & Display>
AZL>
Times
Params & Display>
AZL
Params & Display>
AZL>
eBUS
Params & Display>
AZL>
Modbus
SCC Inc. Page 36 Section 3
