Siemens LMV51.140C1 Technical Instructions

LMV Series
Technical Instructions
LV5-1000
Menu Path Parameter Default Range Description
51.1 52.2 52.4
LEGEND - Password Access: (U)=User, (S)=Service, (O)=OEM, Shaded = Commonly Used, ** = Must Set, X = Has Function, / = Partial Function
LMV
Max Stat Dev (U)
Records the maximum VSD speed deviation from setpoint during steady state operation
(steady load) during a run period. 0 to 100% of standarized speed.
x x
Max Dyn Dev (U)
Maximum motor speed deviation from setpoint during an acceleration or deceleration of the
motor (changing load) during a run period. Range = 0 to 100%
x x
Num Dev >0.3% (U)
The number of speed dev
iations exceeding 0.3% of the standardized speed at the end of a
modulation event. Max = 255 deviations.
x x
Num Dev >0.5% (U)
The number of speed deviations exceeding 0.5% of the standardized speed at the end of a
modulation event. Max = 255 deviations.
x x
Absolute Speed (U) This displays the real time speed of the blower motor in RPM. Max is 6553 RPM.
x x
ASN (U)
x x
ProductionDate (U)
x x
SerialNumber (U)
x x
ParamSet Code (U)
x x
ParamSet Vers (U)
x x
Params & Display>
VSD Module
SW Version (U) Software version of the VSD control.
x x
O2 Sensor (S) no sensor
no sensor
QGO20
QGO21
Configures the PLL module for the connected O2 sensor.
x x
O2SensServT
im (S) 0 days 0-65535 days
Sets the service interval for the O2 sensor. The time set here is compared against the total
hours run counter. See Operation > HoursRun . Upon expiration of service interval, different
actions will be taken based on O2 trim operating mode. If in 'conAutoDeac', then O2 trim
will auto deactivate. If operating mode is set to 'O2 Control' or 'O2 Alarm', a lockout will
occur. If set to 0, feature is deactivated.
x x
O2SensServTimRes (S) deact
activated
deactivated
Resets the service interval for the O2 sensor. Reset once service work has been completed.
x x
SupAirTempSens (S) no sensor
no sensor
Ni1000
Pt1000
Configures the PLL module for the appropriate ambient air temperature sensor. Sensor is
not required for O2 trim, but is required for the efficiency calculation.
x x
Information concerning the VSD board (pieces internal to the LMV5).
Read Only
Read Only
Read Only
Read Only
Read Only
Read Only
Read Only
Params & Display>
VSD Module>
Process Data
Params & Display>
VSD Module>
ProductID
Params & Display>
O2 Module>
Configuration
SCC Inc. Page 40 Section 3
HOME
HOME
P - LIST
