Technical Instructions LMV Series
Document No. LV5-100
0
Section 1 Page 16 SCC Inc.
Variable Frequency Drive (VFD) Components
Variable Frequency Drives (VFDs) - Optional
Pre-programmed Variable Frequency Drives
(VFDs) are available for use with an LMV52.
Braking resistors and line / load reactors are available as accessories.
DR…
Pre-programmed VFDs with LMV52 programmi
ng
and wiring instructions
Speed Sensor Mounting Kit – Qty (1) Req
uired per VFD
Because the LMV52 requires speed fee
dback when using a VFD, one of the following speed
sensor kits is required if a VFD is present.
AGG5.305
Speed sensor and associated mounting kit with
connections available for mounting directly to ½” or
¾” conduit. Includes speed sensor, 6 foot cable, 3-
finger speed wheel, O-ring for a watertight seal, and
necessary mounting hardware
Range: 300-6300 RPM
AGG5.310
Speed sensor and associated mounting kit.
Includes
speed sensor, 6 foot cable, 3-finger speed wheel,
and necessary mounting hardware
Range: 300-6300 RPM
Explosion Proof Housing – Optional
An explosion proof housing is available
for speed sensor kit AGG5.310.
LMV5-XPR-SS
Explosion proof housing for speed sensor kit
AGG5.310
