8. Valve Body
9. O-Ring
10. Spring
11. Air Loaded Piston
12. O-Ring
13. O-Ring
14. Spring Loaded Piston
15. Compensation Plate
16. Compression Spring
17. Compression Plate
18. Retaining Base
19. Retaining Ring Clip
20. Ball 5/32”
21. Set Screw
22. O-Rings (3 total)
23. Air Signal Manifold
24. Screw 3/8”
25. Screw 1/2”
To Valve
Cap
Figure 4-30 Valve Body Exploded View
Align Pin with Index Hole
V16022
(Air Loaded)
V16023
(Spring Loaded)
Figure 4-31 Valve Base Alignment Pin
Valves
4.6 Model 11 Valve
Maxum II Valves and Oven Components
90 Service Manual, 10/2018, A5E42019844001
