08/2005 ShopTurn Functions
5.1 Strai
g
ht or circular
p
ath movements
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-159
Straight >
¾ Press the "Strai. Circle" and "Straight" softkeys.
Rapide
traverse
¾ Press the "Rapid traverse" soft key if you want to use rapid
traverse instead of a programmed machining feedrate.
Parameters Description Unit
X
Z
Y
C1
C3
Z3
Target position in the X direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Z direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of C axis of main spindle (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of C axis of counterspindle (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of special axis (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
mm
mm
mm
mm
F Machining feedrate mm/rev
mm/min
mm/tooth
Radius
compensation
Input defining which side of the contour the tool machines in the programmed
direction:
Radius compensation to right of contour
Radius compensation to left of contour
Radius compensation off
The previously programmed setting for radius compensation is used
