08/2005 ShopTurn Functions
5.1 Strai
g
ht or circular
p
ath movements
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-163
5.1.5 Polar coordinates
If a workpiece has been dimensioned from a central point (pole) with
radius and angles, you will find it helpful to program these dimensions
as polar coordinates.
Before you program a straight line or circle in polar coordinates, you
must define the pole, i.e. the reference point, of the polar coordinate
system.
Polar >
Pole >
¾ Press the "Strai. Circle", "Polar" and "Pole" soft keys.
Parameters Description Unit
X
Y
Machining plane End face/End face C:
X position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Y position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
Y
Z
Machining plane Peripheral surface/Peripheral surface C:
Y position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Z position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
X
Y
Machining plane End face Y:
X position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Y position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
Y
Z
Machining plane Peripheral surface Y:
Y position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Z position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
X
Z
Machining plane Rotate:
X position of the pole ¬ (abs) or X position of the pole (inc)
Incremental dimensions: The plus/minus sign is evaluated.
Z position of the pole (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
