Siemens MCP 398C Operation/Programming

5
ShopTurn Functions 08/2005
5.11 Callin
g
work offsets
5
♥ Siemens AG, 2005. All rights reserved
5-322 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
5.11 Calling work offsets
You can call work offsets (G54, etc.) from any program.
You can use these offsets, for example, when you want to machine
workpieces with various blank dimensions using the same program.
The offset will, in this case, adapt the workpiece zero to the new
blank.
You define the work offsets in the work offset list (see Sec. "Defining
work offsets"). You can also view the coordinates of the selected
offset here.
Transfor-
mation >
Work
offset >
 Press the "Various", "Transformation", and "Work offset" softkeys.
 Select one of the work offsets or the standard offset.
-or-
 Enter the desired offset directly in the input field.
-or-
Work
offset >
 Press the "Work offset" softkey.
The work offset list is displayed.
-and-
 Select a work offset.
-and-
To
program
 Press the "To program" softkey.
The work offset is loaded into the parameterization screen form.
To deselect the work offsets, select the standard offset or enter zero in
the field.
