08/2005 ShopTurn Functions
5.2 Drilling
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-181
Z0
CP
C0
L0
C1 ...C7
L1 ...L7
End face/end face C and end face Y - Polar:
Z coordinate of the reference point (abs.)
Positioning angle for machining area (only for end face Y)
C coordinate for first position (abs.)
1st position of hole with reference to Y axis (abs.)
C coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Distance to position (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
mm
Degrees
Degrees
mm
Degrees
mm
X0
Y0
Z0
Y1 ...Y7
Z1 ... Z7
Peripheral surface/peripheral surface C - Cartesian:
Cylinder diameter ¬ (abs.)
Y coordinate for first position (abs.)
Z coordinate for first position (abs.)
Y coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Z coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
mm
mm
mm
C0
Z0
C1 ...C7
Z1 ... Z7
Peripheral surface/peripheral surface C - Cylindrical:
C coordinate for first position (abs.)
1st position of hole with reference to Z axis (abs.)
C coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Further positions in the Z axis (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Degrees
mm
Degrees
mm
X0
C0
Y0
Z0
Y1 ...Y7
Z1 ... Z7
Peripheral surface Y:
Reference point in X direction (abs.)
Reference point
Y coordinate for first position (abs.)
Z coordinate for first position (abs.)
Y coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Z coordinate for further positions (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
mm
Degrees
mm
mm
mm
mm
To Next Page
