Siemens MCP 398C Operation/Programming

5
08/2005 ShopTurn Functions
5.2 Drillin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-187
X0
Y0
Z0
α0
αX
αY
L1
L2
N1
N2
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Y coordinate of the reference point – first position (abs.)
Z coordinate of the reference point – first position (abs.)
Angle of rotation of box
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Shear angle of box relative to X axis
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Shear angle of box relative to Y axis
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Column spacing in Y direction
Line spacing in Z direction
Number of columns in Y direction
Number of lines in Z direction
mm
mm
mm
Degrees
Degrees
Degrees
mm
mm
Z0
CP
X0
Y0
α0
αX
αY
L1
L2
N1
N2
End face Y:
Z coordinate of the reference point (abs.)
Positioning angle for machining area
X coordinate of the reference point – first position (abs.)
Y coordinate of the reference point – first position (abs.)
Angle of rotation of box
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Shear angle of box relative to X axis
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Shear angle of box relative to Y axis
Positive angle: Box is rotated counterclockwise
Negative angle: Box is rotated clockwise
Column spacing in X direction
Line spacing in Y direction
Number of columns in X direction
Number of lines in Y direction
mm
Degrees
mm
mm
Degrees
Degrees
Degrees
mm
mm
