Page #225 background imageLoading...
Page #225 background image
5
08/2005 ShopTurn Functions
5.4 Contour turnin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-225
If you want to rough and then finish, you have to call the machining
cycle twice (Block 1 = roughing, Block 2 = finishing). The
programmed parameters are retained on the second call.
If you want to finish a contour more than once, you must program the
machining cycle a corresponding number of times.
Stock
removal
¾ Press the "Cont. turn." and "Stock removal" soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Roughing
Finishing
Stock removal
direction
Stock removal direction: Longitudinal, transverse or parallel to contour.
Machining side Machining side:
For stock removal direction longitudinal and parallel to contour: External or internal
For stock removal direction transverse and parallel to contour: end face or rear side
Machining
direction
Machining direction:
. : From inside to outside
. : From outside to inside
. : From end face to rear side
. : From rear side to end face
The machining direction depends on the stock removal direction and choice of tool.
D Infeed depth for roughing (inc.) mm
DX Infeed depth for roughing in X direction (inc) – (for parallel to contour alternative to D
only)
mm
DZ Infeed depth for roughing in Z direction (inc) – (for parallel to contour alternative to D
only)
mm
Do not round contour at end of cut
Always round contour at end of cut
Round contour automatically at end of cut
Equal cut segmentation
Align cut segmentation to edges
Constant cutting depth
Alternating cutting depth - (only with align cut segmentation to edges)
