Siemens MCP 398C Operation/Programming

5
08/2005 ShopTurn Functions
5.4 Contour turnin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-229
Grooving
¾ Press the "Contour turning" and "Grooving" soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Roughing
Finishing
Stock removal
direction
Stock removal direction: Longitudinal or transverse
Machining side Machining side:
For stock removal in longitudinal direction: External or internal
For stock removal in transverse direction: end face or rear side
D Infeed depth for roughing (inc.) mm
XDA 1. grooving limit tool (inc) – (end face or rear face only) mm
XDB 2. grooving limit tool (inc) – (end face or rear face only) mm
U Finishing allowance in X and Z direction (inc) – (roughing only) – (alternative to UX
and UZ)
mm
UX Finishing allowance in X direction (inc) – (roughing only) – (alternative to U) mm
UZ Finishing allowance in Z direction (inc) – (roughing only) – (alternative to U) mm
Stock
allowance
Compensation allowance for contour or not – (finishing only)
U1 Compensation allowance in X and Z direction (inc) – (with allowance only)
Positive value: Compensation allowance is not removed
Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
DI Distance after which feed interruption occurs - (only for roughing) mm
BL Description of unmachined part: Cylinder. allowance or contour (only for roughing)
XD
Allowance or cylinder dimension in X direction ¬ (abs.) – (for cylinder only)
Allowance or cylinder dimension in X direction (inc.) – (for cylinder only)
Allowance based on contour in X direction (inc.) – (for allowance only)
mm
ZD Allowance or cylinder dimension in Z direction (abs. or inc.) – (for cylinder only)
Allowance based on contour in Z direction (inc.) – (for allowance only)
mm
Set machining
area limits
Limit machining area or not
XA Limit X (abs) – (with limited machining area only) mm
XB Limit X (abs or inc) – (with limited machining area only) mm
ZA Limit Z (abs) – (with limited machining area only) mm
ZB Limit Z (abs or inc) – (with limited machining area only) mm
N Number of grooves
